Description
GENERATOR SET SPECIFICATIONS
Model： FM-500GFZ
Frequency: 50Hz /60Hz
Rated power: 500KW/625KVA
Weight：22000kg
Size：6400*1600*2900mm
ENGINE：
Engine Model: 8300D/M-2
No. Of Cylinder: 6
Bore *stroke:300*380mm
Aspiration model: non-turbocharged
Ignition method: plug ignition
Gas pressure:3~20Kpa
Start motor: Compressed air
ALTERNATOR：Hengjiu
Exciter type: Brushless, self-excited
OUtput model: 3H4W
Insulation grade: H
Protection grade: IP23
Optional brand: Marathon, Engel , Stanford
Controller: Smartgen
Model:HGM6110
Protective functions:
Low oil pressure
High water temperature
High/low voltage
High Engine Temperature and Overspeed
Voltage regulator frequency regulator
Emergency stop
Start failure
Optional brands: Deepsea, ComAp.
