Description
GENERATOR SET SPECIFICATIONS
Model： FM-2000GFT
Frequency: 50Hz /60Hz
Rated power: 2000KW/2500KVA
Weight：22000kg
Size：6070*2380*2776mm
ENGINE：
Engine Model: L20V190ZLT-2
No. Of Cylinder: 20
Bore *stroke:190*255mm
Aspiration model: Supercharging, inter cooled
Ignition method: plug ignition
Gas pressure:8~200Kpa
Start motor: 24V
ALTERNATOR：Liuzhou Siemens
Exciter type: Brushless, self-excited
OUtput model: 3H4W
Insulation grade: H
Protection grade: IP23
Optional brand: Marathon, Engel , Stanford
voltage control model: AVR
Controller: Smartgen
Model:HGM6110
Protective functions:
Low oil pressure
High water temperature
High/low voltage
High Engine Temperature and Overspeed
Voltage regulator frequency regulator
Emergency stop
Start failure
Optional brands: Deepsea, ComAp.
